100% Firmware V1.5 PIC18F25K80 ELM327 Bluetooth V1.5 OBD2 Car Diagnostic Tool ELM 327 V1.5 Work On Android/Symbian BEST Quality

Color: Blue 2PCB White 2PCB White 1PCB Blue 1PCB Black 1PCB Black 2PCB
List price: US $5.25
Price: US $4.99
You save:US $0.26 (5%)

Item Specifics

Brand Name:
toobdpro
Item Type:
Car Diagnostic Cables and Connectors
Item Length:
10cm
Power:
W
Model Name:
OBD2 Scan Frimware V1.5 Version
Special Features:
Bluetooth
Item Weight:
0.05kg
Material Type:
Plastic
Software Version:
V2.1
Voltage:
V
Hardware Version:
V1.5
Electronic:
No
Item Height:
2cm
Item Width:
5cm
Item Name:
ELM327 Super MINI
Color:
Blue
OBD2 Type:
Code Reader Scan Tool
Language:
Multi-Language
Connection:
Bluetooth
Supports Platform:
Android Torque/Symbian/Windows
OBD2 CAN-BUS:
Supports Multi-Protocols
Performance:
V1.5 Hardware Stable
Note:
No Supports Truck/Diesel Cars
Function:
Read and delete Fault code

Product Description

About Shipping Method:
  • Order you choose and ship by “China Post Oridinary Small Packet Plus”,No track information after despatch from China (Can't track),but which save your shipping fee. (Buyer protection time is 60days,Brazil 90days)
  • Please read this and note before your order. Do not open dispute before 60days.
  • OR You can pay extra Registered shipping fee to choose China Post Registered Air Mail with details track information.

Type 1:

Normal 2PCB With PIC18F25K80 Chip,included CD and Electrostatic bag

Type 2:

New 1PCB With PIC18F25K80 Chip ,no CD and Carton Box with QR Code

ELM327 hardware V1.5 MAC address is aa:bb:cc:11:22:33

This ELM327 is bluetooth module Firmware V1.5 with PIC18F25K80 Chip.

Firmware V1.5 supports more cars and more protocols than firmware V2.1. Firmware V1.5 has very stable function and it supports SAE J1850 PWM and SAE J1850 VPW protocols.

So if your V2.1 can not works with your car protocols,mabe you could buy Firmware V1.5 to try ,but it doesnt means V1.5 can supports your car 100%,as we can not test each car .

Note:ELM327 only works Gasoline cars,it can not work Diesel&trucks.

We promise you buy this link firmware V1.5,we will only send V1.5 version to you ,so please do not worry and buy it !

We welcome every customer buy and test it ,give us feedback about the hardware Version V1.5,as we have confident to proof it.

This ELM327 works ONLY for Gasoline cars,it does not supports Diesel car and Truck.

It supports multi-brand gasoline cars,but we can't test it on all cars ,also each car brand has many series,so we can not make sure if this device works your car or not .

We suggest you can buy one to try and test . As this is cheap elm327,but it has powerful function for your car !

But if you dont sure and do not want to buy one to try ,please consider twice.

ELM327 OBD2 Code Reader Scanner Auto Diagnostic Interface V1.5

Firmware Adapter Version V1.5+25K80 Chip

Description:

ELM327 MINI OBD SCAN is the newly developed wireless scan tool. It supports most standard OBD-II protocols.

Works For Multi-Cars diagnostic,read and delete Fault code.

Highlights:

Hardware V1.5,Software V2.1
Bluetooth Password :0000 / 1234
Woks on Android Torque (Android 4.0~4.4) /PC,BUT IT NO WORKS iOS!
It CAN'T support Diesel or Trucks.
This ELM327 Hardware V1.5 supports All OBD-II protocols cars ,but it can not do all car models,please check your car with following protocols.
Supprots All Protocols:
SAE J1850 PWM (41.6 kbaud)
SAE J1850 VPW (10.4 kbaud)
ISO9141-2(5 baud init,10.4Kbaud)
ISO14230-4 KWP(5 baud init,10.4 Kbaud)
ISO14230-4 KWP(fast init,10.4 Kbaud)
ISO15765-4 CAN(11bit ID,500 Kbaud)
ISO15765-4 CAN(29bit ID,500 Kbaud)
ISO15765-4 CAN(11bit ID,250 Kbaud)
.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings (user adjustable)
Functions:
1.Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
2.Clear trouble codes and turn off the MIL (“Check Engine” light)
3.Display current sensor data, including:
4.Engine RPM
5.Calculated Load Value
6.Coolant Temperature
7.Fuel System Status
8.Vehicle Speed
9.Short Term Fuel Trim
10.Long Term Fuel Trim
11.Intake Manifold Pressure
12.Timing Advance
13.Intake Air Temperature
14.Air Flow Rate
15.Absolute Throttle Position
16.Oxygen sensor voltages/associated short term fuel trims
17.Fuel System status
18.Fuel Pressure
19.Many others.
Default Settings(user adjustable)
1.Works with OBD-II compliant vehicles
2.Wireless (Bluetooth) 5~10 meter
3.Software included for Pa, PDA,Mobile
4.Software included for Windows PC ,Can also be used with a PC with a Bluetooth Card.
5.Software included for Windows Smartphone Android torque
Package List:
1 x ELM327 Bluetooth
1 x CD
Note:If CD unreadable or damaged,please contact us send you download link .Do not open dispute or negative feedback. Thanks .

Q:What version of this ELM327?
A: Firmware V1.5,SoftwareV2.1
Q:What Chip of this firmware V1.5?
A:Best PIC18F25K80 Chip
Q:How many language of this device software?
A:Czech,Danish,German,English,Spanish,French,Croatian,Hungarian,Italian,Polish,Serbian,Turkish
Q:Does it supports Russian Language?
A:Sorry,the CD software has no Russian yet. But if you install torque on your Russian language phone,it will shows Russian language on your Torque App .
Q:Does it supports WIFI and iOS?
A:No,it only supports bluetooth android torque/Symbian and windows.
Q:Does firmwareV1.5 better than V2.1?
A:Yes,firmwareV1.5 is more stable than V2.1 ,also from many buyer feedback,V1.5 supports more protocols and car brand .
Q:Does this device works diesel car or truck?
A:No,it works only gasoline cars ,supports most OBDII Standard protocols.
Q:How can i know if this device works my car or not ?
A:this ELM327 works most gasoline car brand model,but we can not sure if your car supported,we have no test each car .You can buy one to test.
Q:How is the step for Run software on android phone?
A:Open your android phone software–Setting–Connecting Type–OBD2 Adapter Setting–Bluetooth–Choose Bluetooth Device–OBDII.
Q:My android phone connect to my old ELM327 before ,do i need delete previous informations?
A:Yes,please delete all old informations ,so make sure you can connect your new ELM327.

CD Soft ware Multi-Language:

Works on Android Bluetooth Torque for Reference:

Software Install on Windows Computer For Display:

Computer detected interface version V1.5 with PIC18F25K80 Chip
